EDGE FREE® acoustically transparent fixed frame screen
Sonic AT8 ISF eFinity (EDGE FREE)
Compatible Projection :
EPV’s Sonic AT8 ISF eFinity is an EDGE FREE® acoustically transparent fixed frame screen. It uses an ultra-fine front projection material designed for 4K and 8K high-resolution projectors to provide exceptional video and audio performance.
The Sonic AT8 ISF material is a multi-layer, tightly knitted fabric with a bonded black backing which eliminates light loss. It has earned the world-renowned ISF Certification for providing a flat spectral response and rendering accurate colors in a dark room environment.
“The Sonic AT8 isf eFinity projection screen was a pleasure to assemble and use. I was unable to find any of the drawbacks that often come with acoustically transparent projection screens.” – Doug Blackburn, Widescreen Review
| Sonic AT8 ISF | Gain | Viewing Angle | Description |
|---|---|---|---|
 | 1.0 | 180° | ISF-certified, acoustically transparent fine-weave screen material. Its integrated black backing prevents light bleed, delivering moire-free clarity and accurate color for 4K/8K Ultra-HD projectors. Visit Screen Material Page |
Screen Material
- Sonic AT8 ISF 1.0 Gain sound transparent front projection material
- Multilayer ultra-fine knit design for high resolution projectors and negates the formation of moiré effect
- Integrated black backing eliminates back-lighting (reflection)
- Ultra-short throw projector friendly, allowing for placement of a center channel speaker
- Ultra-wide viewing angle allows viewers to see a bright, clear image from any angle
- ISF Certified for accurate color reproduction – An industry standard for high fidelity video display systems
- Outstanding, reference-grade sonic transparency
- 4K/8K Ultra HD Ready
- Compatible with ultra/short, and standard throw projectors
- Available in diagonal sizes:
- 110″, 120″, 135″, 150″, 165″ and 180″ in 16:9 Aspect ratio
- 138″, 158″, 166″ and 176″ in 2.35:1 Aspect Ratio
Design and Installation
- Sleek EDGE FREE® Fixed Frame design maximizes viewing area in a smaller footprint
- Ultra-thin (9 mm) black bezel trim
- Lightweight aluminum split-frame design is cost effective for shipping and provides easy access to install sites
- Sliding wall mounting brackets allow horizontal movement of screen to ensure precision on-axis alignment
- LED Backlighting kit included
Sonic AT8 ISF eFinity Fixed Frame Models
| Model Number | Nominal Diagonal | Aspect Ratio | Viewable Area | Screen Material | Gain | Frame Width |
|---|---|---|---|---|---|---|
| EF110H-AT8-ISF | 110″ | 16:9 | 53.9″x95.9″ | Sonic AT8 ISF | 1.0 | 0.4″ |
| EF120H-AT8-ISF | 120″ | 16:9 | 58.8″x104.6″ | Sonic AT8 ISF | 1.0 | 0.4″ |
| EF135H-AT8-ISF | 135″ | 16:9 | 66.1″x117.6″ | Sonic AT8 ISF | 1.0 | 0.4″ |
| EF150H-AT8-ISF | 150″ | 16:9 | 73.5″x130.7″ | Sonic AT8 ISF | 1.0 | 0.4″ |
| EF138C-AT8-ISF | 138″ | 2.35:1 | 54.1″x127.2″ | Sonic AT8 ISF | 1.0 | 0.4″ |
| EF158C-AT8-ISF | 158″ | 2.35:1 | 62.0″x145.6″ | Sonic AT8 ISF | 1.0 | 0.4″ |
