Fixed Frame Screen

DarkStar®

The DarkStar® is a front projection screen material with ambient light rejecting properties. It has been designed for use in environments where ambient light cannot be entirely controlled. An added value is that it works exceptionally well in improving contrast in dark room environments as it does with high levels of ambient light.

The DarkStar® is a true optical lens based front projection screen material. Its specialized filter design eliminates ambient light wash-out by reflecting only the direct projected image. At the same time it deprives secondary luminosity from having an adequately reflective angle. The results are superior image brightness levels with enhanced contrast and color neutrality.

DarkStar® GainViewing
Angle
Description
EPV Screens projection screen in neutral gray color for custom installation.1.470°DarkStar® is a 0.3mm retro-reflective ALR screen material. Absorbing 95% of overhead and lower ambient light, its optical filters and neutral black tint deliver high gain, strong contrast, and accurate 4K, HDR, and 3D color.
Visit Screen Material Page

DarkStar® Product Video

Features & Benefits

  • Gain: 1.4
  • Viewing Angle, Horizontal: 70° (35° L/R)
  • Viewing Angle, Vertical: 32° (16° up/down)
  • Direct Light Reflection Technology
  • DarkStar® material absorbs 95% of ambient light from above and below
  • Special neutral black tint maintains, color balance and contrast with high gain
  • 4K Ultra HD, Active 3D, and HDR Ready
  • Scratch-resistant protective outer coating
  • Multiple layers interact Artifact-free without glare on the outer protective surface

DarkStar® screen info

Thickness 0.3 mm
Peak-gain 1.4
Lenticular Pitch 0.065 mm
Horizontal half-gain 35 degrees
Vertical half-gain 16 degrees
Soft-edge blending No
Tiling possibility No
Curving possibility Yes
Rolling possibility Yes
Min. Lens-Throw-Ratio 1.8:1
PDF Video
User Guide (Standard Version) Download •
User Guide (SE Version) Download •
Dimensions (Standard Version) Download •
Dimensions (SE Version) Download •

For more information, go to Reseller Zone
